SY22644FCC (SY59116FCC)

Production
Dimmable, high Efficiency Linear Driver With Integrated 500V MOSFET
Datasheet
SY22644FCC Dimmable, high Efficiency Linear Driver With Integrated 500V MOSFET Datasheet
    Part NumberSY22644FCC
    DescriptionLinear PWM Dimming, Int. MOS 500V
    PackageSO8E
    Io_max (A)0.07
    Input Type120Vac,230Vac
    Po_max (W)
    PF (>)
    ApplicationAC Linear PWM Dim

    • Analog Dimming Available
    • Integrated 500V MOSFET
    • Lower than 1% Deep Dimming Level
    • Power Factor >0.6
    • Up to 87% High Efficiency
    • SMT Assembly
    • Eliminate Magnetic Components
    • Compact Package: SO8E



    Evaluation Board

    • 2022-02-22_090554

      Photo of evaluation board

    • 2022-02-22_090538

      Photo of evaluation board

    EVB_SY22644FCC

    The EVB_SY22644FCC is intended for evaluating  AC 200~240V input, 270V/32mA output Dimmable, high Efficiency Linear Driver With Integrated 500V MOSFET
