• High Efficiency 5A 1.5MHz Buck Mode Charger

- Support 3.9V-14V Input Voltage Range

- Programmable IDPM/VDPM to Support the USB and Adapter

- Support USB SDP/DCP/CDP and Non-Standard Adapter Detection

- 3.84-4.608V Adjustable Charge Voltage

- Support Narrow VDC Power Path Management

- JEITA Compliance

- ±0.5% Charge Voltage Regulation

- Accelerate Charge Time by Battery Path Impedance Compensation

- Charge Status Outputs for LED or Host Processor

• Maximum 2.4A 500KHz/1.5MHz Boost OTG Current

- 4.55-5.51V Adjustable OTG Output Voltage

- Selectable OTG Output Current Limit

- Up to 2.4A OTG Current Limit on BUS

- ±1.5% Output Regulation in Boost Mode

• Battery Monitor for Voltage, Temperature and Charge Current Measurements
• Full BATFET Control to Support Shipping Mode, Wake Up, and System Reset
• Up to 9A Battery Discharge Current
• Safety

- Battery Temperature Sensing for Charge and Boost Mode

- Battery Charging Safety Timer

- Thermal Regulation and Thermal Shutdown

- Input/System Over-voltage Protection

- MOSFET Over-current Protection

• Low Battery Leakage Current and Support Shipping Mode
• 4mm × 4mm QFN-24 Package
