SY22102ADC (SY7201ADC)

Production
30V High Current Boost LED Driver
Datasheet
SY22102ADC 30V High Current Boost LED Driver Datasheet
    Part NumberSY22102ADC
    Fsw (MHz)1
    Dimming ModePWM
    Channels1
    PackageTSOT23-6
    Vin_min (V)2.8
    Vin_max (V)30
    Vo_max (V)
    Io_max (A)0.3
    Features / Special FunctionBoost
    ApplicationHandheld devices Backlight
    • Input Voltage Range: 2.8 to 30V
    • Switch Current Limit: 2A
    • Drives LED Strings up to 30V
    • 1MHz Fixed Frequency Minimizes the External Components
    • Dimming Frequency for EN/PWM Pin:20kHz~1MHz
    • Internal Soft-start Limits the Inrush Current
    • Open LED Over Voltage Protection
    • RoHS Compliant and Halogen Free
    • Compact Package: TSOT23-6

    Evaluation Board

    • 2022-02-09_153647

      Photo of evaluation board

    • 2022-02-09_153634

      Photo of evaluation board

    • 2022-02-09_153701

      Photo of evaluation board

    EVB_SY22102ADC

    The EVB_SY22102ADC is intended for evaluating 30V High Current Boost LED Driver.

    Technical Documentation
