• Wide Input Voltage Range: 4.5 to 18V
• Up to 1.2A Continuous Load Current Capability
• Low RDS(ON): 110mΩ at VIN=12V
• Programmable Blanking Time for DFF Control
• Default ON when EN high
• Low Shutdown Current
• Controlled Turn-On Slew Rate to Avoid Inrush Currents
• Over Temperature Shutdown with Auto Recovery
• RoHS Compliant and Halogen Free
• Compact Package: SO8

The SY20804/SY20804A is a compact, low RDS(ON) load switch designed to deliver a continuous current of up to 1.2A. It functions across an input voltage range of 4.5V to 18V.

The SY20804/SY20804A includes a DFF (D Flip Flop) input, allowing the user to control the load switch on and off states. When the DFF pin is pulled low for a duration exceeding the programmable blanking time, tBLK (set by CT), the device will switch its output state. If the duration of the low level on the DFF pin is less than tBLK, the device will maintain its previous output state.

The SY20804/A is available in a compact SO8 package.
