| Part number | SY20834DBC |
|---|---|
| Vin (min) (V) | 2.5 |
| Vin (max) (V) | 15 |
| Vabs cont. (max) (V) | 30 |
| Iout (max) (A) | 4 |
| Protection mode | OCP,VCP,OTP |
| Over current response | Current limiting |
| Current limit (A) | Adjustable |
| Fault response | Auto-recovery |
| Ron (typ) (mΩ) | 50 |
| Certification recognition | |
| Iq (typ) (uA) | 200 |
| Enable logic | High |
| Soft start | Adjustable |
| Features | 3.3V/5V/12V clamping voltage, Programmable Current Limit |
| Package | DFN3×3-10 |
| Operating temperature range(°C) | -40 to 85 |
| Functional safety category |
The SY20834 is a programmable current limit switch with input voltage range selection and output voltage clamping. Extremely low RDS(ON) of the integrated protection N-channel FET helps to reduce power loss during the normal operation. Programmable soft-start time controls the slew rate of the output voltage during the start-up time. Independent enable control allows the complicated system sequencing control. It integrates the overtemperature protection shutdown and auto-recovery with hysteresis.
This IC along with small DFN3X3-10 footprint provides small PCB area application.
Photo of evaluation board
Photo of evaluation board
Photo of evaluation board
The EVB_SY20834DBC is intended for evaluating the programmable current limit switch with input voltage range selection and output voltage clamping.
