SY22698FCC (SY59013FCC)

Production
High Efficiency Linear AC/DC Driver With Integrated 500V MOSFET
Datasheet
SY22698FCC High Efficiency Linear AC/DC Driver With Integrated 500V MOSFET Datasheet
    Part NumberSY22698FCC
    DescriptionLinear, Int. MOS 500V/20Ω
    PackageSO8E
    Io_max (A)0.07
    Input Type120Vac,230Vac
    Po_max (W)10
    PF (>)0.7
    ApplicationAC Linear non-dim
    • Integrated 500V MOSFET
    • Power Factor >0.5 or >0.7
    • Up to 88% High Efficiency
    • ±3% Output Current Precision
    • SMT Assembly
    • Eliminate Magnetic Components
    • Adjustable Thermal Fold Back
    • Compact Package: SO8E

    Evaluation Board

    • 2022-02-21_180208

      Photo of evaluation board

    • 2022-02-21_180217

      Photo of evaluation board

    EVB_SY22698FCC

    The EVB_SY22698FCC is intended for evaluating  AC 108~132V input, 130V/75mA output High Efficiency Linear AC/DC Driver With Integrated 500V MOSFET
