SA21345SFCP

Production
36V, 300mA LDO Regulator
Datasheet
SA21345SFCP 36V, 300mA LDO Regulator Datasheet
    Part numberSA21345SFCP
    Vin (max) (V)36
    Vin (min) (V)4
    Iout (max) (A)0.3
    Output typeAdjustable
    Vout (max) (V)36
    Vout (min) (V)0.6
    Iq (typ) (uA)7
    PSRR at 100kHz (dB)35
    Accuracy (±%)2
    FeaturesEnable, Fixed soft-start,Auto-discharge,Low Iq,Over current protection,Thermal shutdown
    Operating temperature range(°C)-40 to 125
    PackageSOP8E
    Functional safety categoryFunctional safety capable
    • Wide Input Voltage Range: 4V to 36V
    • 300mA Maximum Load Current
    • Low Dropout Voltage (300mV@300mA)
    • Low Quiescent Current (7 µA typ.)
    • Low Shutdown Current (5µA max.)
    • Stable with Tantalum or Ceramic Capacitors
    • Excellent Load and Line Regulation
    • Enable Control Input
    • Over Current Protection
    • Thermal Shutdown
    • Compact SOP8E Package
    • Automotive AEC-Q100 Grade 1 Qualified
    • Moisture Sensitivity Level (MSL): 1

    The SA21345S is an automotive grade, low-dropout voltage regulator for high input voltage and ultra-low quiescent current applications.

    The SA21345S provides resistor adjustable output voltage with ±2% reference accuracy over temperature and low drop out (300mV at 300mA). It offers protection features including over-current protection, thermal shutdown, and stable operation with low ESR ceramic or tantalum capacitors due to the optimized internal compensation.

    The SA21345S is available in a compact SOP8E package.
