• Wide Input Voltage Range 5V to 28V
• Current Accuracy for Whole Temperature Range:

• ±3.5% per device when IOUTx>30mA
• Different Channels Matching Accuracy ±1.5% when IOUTx>30mA

• Low Dropout Voltage:

• Maximum Dropout Voltage:240mV@60mA 25℃
• Maximum Dropout Voltage:660mV@150mA 25℃

• Thermal Foldback Function TFB=110 ℃ (TEMP Floating) TSD=160℃(50% IRATED)
• Parallel Outputs for Higher Current Using Multiple ICs or Multiple Channels of a single IC
• Short LED Detection, Single LED Short Detection and Open LED Detection with Deglitch Timer
• Separate Single LED Short Fault pin and open/short led fault pin
• Compact package: TSSOP16E
• AEC-Q100 Qualified with the Following Results:

• Device Temperature Grade1: –40°Cto125°C Ambient Operating Temperature Range

The SA32707A is a three-channel linear led driver integrated with low drop-out MOSFET. It is intended to deliver up to 0.15A output current on each channel. Three independent PWM dimming pins are available to achieve ON OFF dimming function for each channel. Measuring the voltage at input and output pin gives accurate open led protection and short led protection.
