Wide Common-mode Voltage Range, VCM: –0.2V to +70V

Low Input Bias Currents, IB: 500pA (Typ.)

Fixed Gain: 200V/V

High-Accuracy:

–      Offset Voltage, VOS: ±50μV (Max.)

–      Offset Drift: ±0.5μV/°C (Max.)

–      Gain Error: ±0.6% (Max.)

–      Gain Drift: ±15ppm/°C (Max.)

–      Common-mode Rejection Ratio: 134 dB (Min.)

Low Supply Voltage, VCC: 1.8V to 5.5V

Low Quiescent Current, IQ: 62μA (Typ.)

Package: SOT363

MSL Rating: MSL1

The SQ52133E is a 200V/V fixed Gain, low-power, highprecision, high-side or low-side current-sense amplifier with ultra-low input bias current, suitable for bidirectional or unidirectional current measurements. The common mode voltage range of the SQ52133E is from -0.2V to +70V, independent of the supply voltage. The SQ52133E has an ultra-low input bias current (500pA typical). Compared with other current-sense amplifiers, this feature allows larger current-sense resistors to be used to enable current measurements in the microampere range. The supply voltage range of the SQ52133E is 1.8V to 5.5V and the device draws 62µA quiescent current. It is offered in a SOT363 package and is specified over the extended industrial temperature range of -40°C to 125°C.
