• Senses Bus Voltages from 0 V to 36 V
• High-Side or Low-Side Sensing
• Bi-directional Current Sensing
• Reports Current, Voltage, and Power
• High Accuracy:
•    - 0.02% Gain Error (Typ) for Shunt Voltage
•    - 0.02% Gain Error (Typ) for Bus Voltage
•    - 2.5μV Offset (Typ) for Shunt Voltage
•    - 1.25mV Offset (Typ) for Bus Voltage
• Configurable Averaging Options
• Configurable Conversion Time
• Abundant Alert Sources Setting
• 16 Programmable Addresses
• High Speed I2C Mode Compatible
• Operates from 2.7V to 5.5V Power Supply

• MSL Rating: MSL3

The SQ52201E which has an I2C or SMBUS-compatible interface, is a high accuracy device with the features of current shunt, bus voltage and power monitor.

The shunt voltage and the bus supply voltage could be sampled accurately at the same time and will be processed inside the device to generate the power data with programmable calibration, averaging technique and internal multiplier. It makes the application system more reliable because of abundant alert sources settings provided by programmable alert function.

The current on common mode bus voltages can be monitored by SQ52201E. The common mode bus voltages can vary from 0V to 36V, which is independent of the supply voltage, ranging from 2.7V to 5.5V. The operating temperature of SQ52201E ranges between –40°C and +125°C. The SQ52201E is available in the MSOP-10 package and features 16 programmable addresses on the I2C-compatible interface.
