SY20217DQDC

High Efficiency Buck Converter with Low Power Mode And Output Voltage Selection

SY20217DQDC High Efficiency Buck Converter with Low Power Mode And Output Voltage Selection Datasheet

Parameters
Features
Description

Part Number	SY20217DQDC
Vin_min (V)	2.5
Vin_max (V)	5.5
Io_max (A)	4
Channels
Vo_min (V)	0.7
Fsw (MHz)	1
Vref (V)
Vref Accuracy
Iq (uA)	30
Rdson1	70
Rdson2	40
Soft Start	0.1
Package	QFN3x3-16
Topology
Protection Mode	OVP,Latch-off SCP
Features / Special Function	Power Good Indicator,VID control
Temp Range

2.5V to 5.5V Input Voltage Range
Low R_DS(ON) for Internal Switches (PFET/NFET): 70mΩ / 40mΩ
4A Continuous, 7A Peak Load Current Capability
±1% Output Voltage Accuracy at PWM Mode
PFM Mode at Light Load for High Efficiency
Selectable Fixed Output Voltage Through VID0, VID1 Pin
Support for Low Power Mode Logic Input
Typical 30µA Typical Quiescent Current
Ultra Fast Load Transient Performance
Flexible MODE Pull Down Resistor to Program the Required Power Rail
Power Good Indicator
OVP/SCP/OTP Latch-off Protection
RoHS Compliant and Halogen Free
Compact Package: QFN3×3-16

The SY20217D is a high efficiency Buck converter with low power mode and output voltage select function. The output voltage can be changed by the VID0, VID1, and LP pins with dedicated setting slew rate. It therefore supports dynamic voltage scaling function target.

The SY20217D operates over a wide input voltage range from 2.5V to 5.5V. It is available in a QFN3×3-16 package.
