SY2A27317AUYS (SA21305AUYS)

Production
1350mA High Accuracy Current Limit Low Dropout Regulator
Datasheet
SY2A27317AUYS 1350mA High Accuracy Current Limit Low Dropout Regulator Datasheet
    Part numberSY2A27317AUYS
    Vin (max) (V)3.3
    Vin (min) (V)1.65
    Iout (max) (A)1.35
    Output typeAdjustable
    Vout (max) (V)3.3
    Vout (min) (V)0.6
    Iq (typ) (uA)160
    PSRR at 100kHz (dB)23
    Accuracy (±%)2
    FeaturesEnable,Fixed soft-start,Auto-discharge,Over current protection,Output short to ground protection, Foldback Current Limit, Thermal shutdown
    Operating temperature range(°C)-40 to 105
    PackageCSP2.4×2.4-36
    Functional safety category
    • Input Voltage Range: 1.65V to 3.3V
    • Output Current up to 1350mA
    • PSRR at 1kHz : 55dB(Typ)
    • Adjustable Output FB Voltage Accuracy : ±1% @TA=25˚C
    • Drop Output Voltage : Max=0.4V
    • Packages CSP 2.4mm×2.4mm -36
    • RoHS Compliant and Halogen Free
    • AEC Q100 Grade 2
    • -40˚C to +105˚C Ambient Temperature Range

    The SY2A27317A is a 1350mA high current capacity linear regulator that provides high output accuracy, fast line and load transient response. The device offers protection features including over current limit, output short protection and over temperature operation.

    The SY2A27317A is available in compact with CSP2.4mm×2.4mm-36 package.
