SY2A27352IFCP (SA21340IFCP)

Production
36V 300mA LDO with Programmable Reset
Datasheet
SY2A27352IFCP 36V 300mA LDO with Programmable Reset Datasheet
    Part numberSY2A27352IFCP
    Vin (max) (V)36
    Vin (min) (V)4
    Iout (max) (A)0.3
    Output typeFixed
    Vout (max) (V)3.3
    Vout (min) (V)3.3
    Iq (typ) (uA)15
    PSRR at 100kHz (dB)35
    Accuracy (±%)2
    FeaturesEnable,Fixed soft-start,Power good,Auto-discharge,Low Iq,Over current protection,Output short to ground protection (hiccup mode),Thermal shutdown
    Operating temperature range(°C)-40 to 125
    PackageSOP8E
    Functional safety category
    • High-current Capability: 300mA Over Full Temperature Range
    • Low-dropout Voltage of 300mV at Full Load 300mA
    • Fixed 3.3V Output Voltage
    • Low Ground Current
    • Over Current Limit Protection
    • Output Short Circuit Protection (Hiccup Mode)
    • Over Temperature Protection
    • Reset Output with Programmable Timeout Period
    • Packages: SO8E
    • RoHS Compliant and Halogen Free
    • Automotive AEC- Q100 Grade 1 Certified



    The SY2A27352I is a 300mA high current capacity linear regulator, which features ultra-low ground current and low dropout voltage. The SY2A27352I has a fixed 3.3V output voltage. The device with fully protection includes over current limit, output short protection and over temperature operation.
