SY2A27357DAAA (SA21345DAAA)

Production
36V Input, 150mA LDO Regulator
Datasheet
SY2A27357DAAA 36V Input, 150mA LDO Regulator Datasheet
    Part numberSY2A27357DAAA
    Vin (max) (V)36
    Vin (min) (V)4
    Iout (max) (A)0.15
    Output typeFixed
    Vout (max) (V)5
    Vout (min) (V)5
    Iq (typ) (uA)15
    PSRR at 100kHz (dB)35
    Accuracy (±%)2
    FeaturesFixed soft-start,Over current protection,Output short to ground protection (hiccup mode),Thermal shutdown
    Operating temperature range(°C)-40 to 125
    PackageSOT23-5
    Functional safety categoryFunctional safety capable
    • Wide Input Voltage Range: 4V to 36V
    • 150mA Maximum Load Current
    • Low Dropout Voltage (150mV @ 150mA)
    • Ultra-low Quiescent Current (15 µA typ.)
    • Stability with Tantalum or Ceramic Capacitors
    • Excellent Load and Line Regulation
    • Over Current Protection
    • Thermal Shutdown
    • Compact SOT23-5 Package
    • Automotive AEC- Q100 Grade 1 Qualified

    The SY2A27357D is an automotive grade, 150mA high current capacity linear regulator. It fixed the output voltage at 5V, which features ultra-low ground current and low drop out voltage. The device offers protection features includes over current limit, output short protection and over temperature protection.

    The SY2A27357D is available in a compact SOT23-5 package.
