SA52106HHP

• 6 Half-bridge Outputs
• 4.5V to 32V Operating Voltage
• Up to 1A Output Current for Each Output
• Low-power Sleep Mode
• Compatible with 5V/3.3V System
• Serial Peripheral Interface, up to 5MHz
• Daisy Chain Functionality
• PWM Capable Output for Frequency 80Hz, 100Hz, 200Hz and 2kHz with 8-Bit Duty Cycle Resolution
• Integrated Protection: Overcurrent Protection (OCP), Short Circuit Protection (SCP), Open Load Detection (OLD), Under Voltage Lockout (UVLO), Over Voltage Protection (OVP) and Thermal Shutdown (TSD)
• nFAULT Pin Output
• AEC-Q100 Qualified

The SA52106 is a six half-bridge motor driver solution for automotive, industrial and other mechatronic applications. The half-bridges are fully controllable to achieve a forward, reverse, coasting and braking operation of motor. All the functions can be programmed through serial peripheral interface (SPI).

The SA52106 provides internal shutdown functions with an nFAULT output pin to alert the system when a fault occurs. Such as over current protection, open load detection, under voltage lockout, over voltage lockout and thermal shutdown. The device is packaged in TSSOP-24 with exposed pad.
