·       Wide Common-mode Voltage Range, V_CM:

–0.2V to +70V

·       Low Input Bias Currents, I_B: 500pA (Typ.)

·       Fixed Gain: 200V/V

·       High-Accuracy:

l   Offset Voltage, V_OS: ±50μV (Max.)

l   Offset Drift: ±0.5μV/°C (Max.)

l   Gain Error: ±0.6% (Max.)

l   Gain Drift: ±15ppm/°C (Max.)

l   Common-mode Rejection Ratio: 134 dB (Min.)

·       Low Supply Voltage, VCC: 1.8V to 5.5V

·       Low Quiescent Current, IQ: 62µA (Typ.)

·       Package: SOT363

·       MSL Rating: MSL1

The SQ52133E is a 200V/V fixed Gain, low-power, high-precision, high-side or low-side current-sense amplifier with ultra-low input bias current, suitable for bidirectional or unidirectional current measurements. The common mode voltage range of the SQ52133E is from -0.2V to +70V, independent of the supply voltage.

The SQ52133E has an ultra-low input bias current (500pA typical). Compared with other current-sense amplifiers, this feature allows larger current-sense resistors to be used to enable current measurements in the micro-ampere range.

The supply voltage range of the SQ52133E is 1.8V to 5.5V and the device draws 62µA quiescent current. It is offered in a SOT363 package and is specified over the extended industrial temperature range of -40°C to 125°C.
