• High Efficiency 5A 1.5MHz Buck Mode Charger

          – Support 3.9V-14V Input Voltage Range

          – Programmable IDPM/VDPM to Support the USB and Adapter

          – Support USB SDP/DCP/CDP and NonStandard Adapter Detection

          – 3.84-4.608V Adjustable Charge Voltage

          – Support Narrow VDC Power Path Management

          – JEITA Compliance

          – ±0.5% Charge Voltage Regulation

          – Accelerate Charge Time by Battery Path Impedance Compensation

          – Charge Status Outputs for LED or Host Processor

• Maximum 2.4A 500KHz/1.5MHz Boost OTG Current

          – 4.55-5.51V Adjustable OTG Output Voltage

          – Selectable OTG Output Current Limit

          – Up to 2.4A OTG Current Limit on BUS

          – ±1.5% Output Regulation in Boost Mode

• Battery Monitor for Voltage, Temperature and Charge Current Measurements
• Full BATFET Control to Support Shipping Mode, Wake Up, and System Reset
• Up to 9A Battery Discharge Current
• Safety

          – Battery Temperature Sensing for Charge and Boost Mode

          – Battery Charging Safety Timer

          – Thermal Regulation and Thermal Shutdown

          – Input/System Over-voltage Protection

          – MOSFET Over-current Protection

• Low Battery Leakage Current and Support Shipping Mode
• 4mm ×4mm QFN-24 Package
