• Temperature Accuracy:

±0.25°C Typical from  0°C to +70°C

±0.75°C Max from 0°C to +70C

• Low Quiescent and Stand by Currents:

6μA Average Quiescent Current (typ.)

1.5μA Standby Current (typ.)

• Power Supplies:

1.8V I/O Power Supply

1.8V Core Power Supply

• Two-Wire Serial Bus Interfaces (I2C and I3C Basic Operation Modes)

• Data Transfer Rate: Up to 12.5MHz in I3C  Basic Mode

• In-Band Interrupt (IBI) for Alerting Host

• Error Detection Functions:

Parity Check for Host Writes

Packet Check for Host Reads and Writes

• 11-bit Resolution with 0.25°C per LSB

• Standard 6-Ball DSBGA (WCSP) Package With 0.5mm Pitch

• MSL Rating: MSL1

The SY64912 is a high-accuracy temperature sensor featuring a I²C/I3C-compliant digital interface. The SY64912 is designed for low-power, high-accuracy thermal monitoring applications and is available in a compact 6-ball DSBGA package.

The SY64912 operates with a core power supply of 1.8V and an I/O power supply of 1.8V. It features a low typical average quiescent current of 6μA during each 125ms conversion.

The SY64912 offers a typical accuracy of ±0.25°C across the full temperature range of 0 °C to +70 °C. It integrates an on-chip 11-bit analog-to-digital converter (ADC) designed to operate with a 1.8V core power supply and a wide I/O power supply from as low as 0.95V to as high as 1.98V. The SY64912 also supports advanced features such as in-band interrupts, parity checks, and packet error checks.
