·       Low R_DS(ON) for Internal MOSFETs: 130mΩ Top, 85mΩ Bottom

·       Wide Input Voltage Range: 2.5V ~ 5.5V

·       Up to 2A Output Current

·       ±1.5% 0.6V Reference

·       PFM Light Load Operation for High Efficiency

·       Internal Soft-Start Limits the Inrush Current

·       1.5MHz Switching Frequency Minimizes the External Components

·       Constant Off-time and Peak Current Mode Control to Achieve Fast Transient Responses

·       100% Dropout Operation

·       Power Good Indicator

·       Output Auto Discharge Function

·       Cycle-by-Cycle Peak Current Limit Protection

·       Hic-Cup Mode Output Under Voltage Protection for SY80082ABT

·       Latch off Mode Output Under Voltage Pretection for SY80082FABT, SY80082LABT

·       Auto-Recovery Mode Over Temperature Protection for SY80082ABT

·       Latch off Mode Over Temperature Protection for SY80082FABT, SY80082LABT

·       Input Under Voltage Lockout (UVLO)

·       RoHS-Compliant and Halogen-Free

·       Compact Package: SOT23-6

The SY80082x high efficiency 1.5MHz synchronous buck converter operates over a wide input voltage range of 2.5V to 5.5V, and can deliver an output current up to 2A. It integrates a top MOSFET and a bottom MOSFET with very low RDS(ON) to minimize conduction loss. The 1.5MHz pseudo-constant switching frequency enables using small external inductor and capacitor values.
