·       Low R_DS(ON) for Internal MOSFETs: 150mΩ Top, 115mΩ Bottom

·       Wide Input Voltage Range: 4.5V ~ 30V

·       Up to 2A Output Current

·       ±1% 0.6V Reference over Temperature from -40°C to 125°C

·       Precise EN Threshold

·       Pulse-Frequency Modulation(PFM) Mode Operation for SY82852

·       Forced Continuous Conduction Mode(FCCM) Operation for SY82852B

·       Internal Soft-Start Limits the Inrush Current

·       Support Smooth Startup with Pre-Biased Output

·       600kHz Switching Frequency Minimizes the External Components for SY82852

·       1200kHz Switching Frequency Minimizes the External Components for SY82852B

·       Advanced Constant On-time and Ripple-Based Control to Achieve Fast Transient Responses

·       Cycle-by-Cycle Valley and Peak Current Limit Protection

·       Hic-Cup Mode Output Under Voltage Protection

·       Auto-Recovery Mode Over Temperature Protection

·       Input Under Voltage Lockout (UVLO)

·       RoHS-Compliant and Halogen-Free

·       Compact Package: SOT23-6

·       Moisture Sensitivity Level (MSL): 1

The SY82852x high efficiency synchronous buck converter operates over a wide input voltage range of 4.5V to 30V, and can deliver an output current up to 2A. It integrates a top MOSFET and a bottom MOSFET with very low RDS(ON) to minimize conduction loss. The high pseudo-constant switching frequency enables using small external inductor and capacitor values.
