• Low RDS(ON) for Internal MOSFETs: 18mΩ Top, 8mΩ Bottom • Wide Input Voltage Range: 4V ~ 25V • Adjustable Output Voltage: 0.6V ~ 2.5V • 6A Continuous Output Current Capability • 660kHz Pseudo-Constant Frequency • ±1% Internal Reference Voltage • Internal 0.6ms Soft-Start Limits the Inrush Current • Constant On-Time and Ripple-Based Control • Excellent Dynamic Performance • Integrated 1Ω Bypass Switch • PFM/USM Selectable Light Load Operation Mode • Power Good Indicator • Output Auto-Discharge Function • Adjustable Valley Current Limit Threshold by ILMT Pin • Cycle-by-Cycle Peak and Valley Current Limit Protection • Latch-Off Mode Output Under Voltage Protection • Latch-Off Mode Output Over Voltage Protection • Latch-Off Mode Over Temperature Protection • Input Under Voltage Lockout (UVLO) • RoHS Compliant and Halogen Free • Compact package: QFN2.5×2.5-16

The SY8386T is a high efficiency synchronous buck converter operating over a wide input voltage range of 4V to 25V and capable of delivering up to 6A current. It integrates low RDS(ON) top and bottom MOSFETs to minimize the conduction loss. It operates at a pseudo-constant frequency of 660kHz, to enable the use of small size inductor and capacitors. The SY8386T also integrates a bypass switch which allows the VCC to be powered by external 3.3V power supply and further reduces the power consumption of the entire system.
