·     Low R_DS(ON) for Internal MOSFET: 38mΩ Top, 19mΩ Bottom

·     Wide Input Voltage Range: 4V ~ 40V

·     Wide Output Voltage Range: 0.6V ~ 24V

·     Support 99% Duty Cycle Operation

·     ±1.5% 0.6V Reference under -40℃ ~ 125℃

·     6A Continuous Output Current Capability

·     Pseudo-Constant Frequency: 500kHz

·     Constant On-time and Ripple-Based Control to Achieve Fast Transient Responses

·     Internal Soft-start Limits the Inrush Current

·     PFM/FCCM Selectable Light Load Operation

·     Selectable Peak and Valley Current Limit Threshold

·     Optional BYP Input for Reducing Power Consumption

·     Power Good Indicator

·     Output Auto-Discharge Function

·     Cycle-by-Cycle Valley, Peak and Reverse Current Limit Protection

·     Hic-cup Mode Output Under Voltage Protection

·     Auto-Recovery Mode Output Over Voltage Protection

·     Auto-Recovery Mode Over Temperature Protection

·     Input Under Voltage Lockout (UVLO)

·     RoHS Compliant and Halogen Free

·     Compact Package: QFN2×3-14

The SY89456 develops a high efficiency synchronous Buck converter capable of delivering 6A continuous. The device integrates top FET and bottom FET with very low RDS(ON) to minimize the conduction loss. In addition, it operates at pseudo-constant frequency of 500kHz under CCM condition to minimize the size of inductor and capacitor. The SY89456 also integrates a bypass switch which allows the VCC to be powered by external 3.3V power supply, further reduce the power consumption of the entire system.
